AK6R SO2R Station
 |
 |
| Left Radio (Run Radio) |
Right Side (Multiplier Radio) |
| Station Description |
Run Side |
Multiplier Side |
| Radio |
Icom 775DSP |
Icom 775DSP |
| Amplifier |
Henry 8K |
Alpha 91b |
| Computer |
"E" Machine - 400 Mhz |
Same |
| CPU Interface |
Icom CT-17 |
Icom CT-17 |
| Monitor |
17 inch Screen |
Same |
| Bandpass Filters |
Dunestar 600 |
Dunestar 600 |
| Filter Switching |
Top Ten Switchbox |
Top Ten Switchbox |
| Coax Stubs (RG-213) |
160-10M |
160-10M |
| Stub Switching |
Top Ten Coax Box |
Icom EX-627 |
| RF Monitor |
Kenwood SM-220 |
Kenwood SM-230 |
| Wattmeters |
Bird 43 - 2500W |
Bird 43 - 2500W |
| Antenna Tuners |
MFJ 986 Differential |
MFJ 986 Differential |
| Rotors |
HAM IV |
Ham IV |
| Contest Software |
Writelog 10.26 |
Writelog 10.26 |
| Logging Software |
DX4WIN |
DX4WIN |
| SO2R Interface |
WX0B Box |
WX0B Box |
| Audio Enhancement |
MFJ Audio Enhancer |
none |
| Antennas |
See Antenna Section |
See Antenna Section |
| FSK Interface |
Homebrew |
Homebrew |
| Headphones |
Heil Proset |
same |
| Speakers |
Icom SP-20 |
Icom SP-20 |
| Microphone Amp |
Writelog Soundboard |
Writelog Soundboard |
| Digital Voice Keyer |
Writelog |
Writelog |
| RTTY Terminal Unit |
Writelog |
Writelog |
| PSK31 |
Writelog/DX4WIN |
Writelog/DX4WIN |
| Packetcluster |
DxTelnet/Writelog |
DxTelnet/Writelog |
| Hand Keys |
Vibroplex Keyer |
Shure Iambic |
|
