| Frequency range: | TX/RX: 144-148 / 440-450 / 1240-1300 MHz RX: 138-174 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5 / 5 / 1 W Lo3: 3.5 / 3.5 / 0.2 W Lo2: 1.5 / 1.5 / 0.2 W Lo1: 0.5 / 0.5 / 0.2 W |
| Voltage: | 6-15 VDC |
| Current drain: | RX: Max 590 mA TX: Max 1.9 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 58*139*49 mm (with BP-100) |
| Weight: | 585 gr (with BP-100) |
| Manufactured: | Japan, 1993-199x |
| Other: | 3*23 memories. Triple RX |
