| Frequency range: | 144-146 / 430-440 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5/5 W, Mid: 0.5/0.5 W, Lo: 15/15 mW |
| Voltage: | 4.8-9.6 VDC with battery pack or 4.6-16 VDC external |
| Current drain: | RX: 35-? mA, TX: Max ? A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 57*125*36 mm |
| Weight: | 380 gr (with BP-171) |
| Manufactured: | 1995-199x |
| Other: | 109 memories. Clock. Detachable speaker/mike. Twin RX New price 1995 in Sweden: 6295:- SEK |
