| Frequency range: | 144-146 / 430-440 MHz |
| Mode: | All-mode |
| RF Power output: | 45/40 W (FM), 35/30 W (SSB/CW) |
| Voltage: | 13.8 VDC |
| Current drain: | RX: 2.5 A, TX: Max 15 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 330*120*330 mm |
| Weight: | 9.2 Kg |
| Manufactured: | 1988-19xx |
| Other: | 23 cm/10W option. Twin RX New price 1988 in Sweden: 17950:- SEK |
| Related documents: |
