| Frequency range: | 144-148 MHz |
| Mode: | FM |
| RF Power output: | Hi: 3 W, Lo: 0.5 W |
| Voltage: | 13.8 VDC +/- 15% |
| Current drain: | RX: 55-270 mA TX: 350-750 mA |
| Impedance: | 50 ohms, SO-239 and whip/rubber duck |
| Dimensions (W*H*D): | 61*183*162 mm |
| Weight: | 1.9 Kg (batteries included) |
| Manufactured: | Japan, 1977?-19xx |
| Other: | XTAL, 15 channels |
