| Frequency range: | 144-146 MHz (5 KHz steps) |
| Mode: | FM |
| RF Power output: | Hi: 1.5 W Lo: 150 mW |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 8-10.8 VDC |
| Current drain: | RX: ? mA TX: ? mA |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 65*167*35 mm |
| Weight: | 450 gr (battery and antenna included) |
| Manufactured: | 1980-19xx |
| Other: | |
| Related documents: |
