| Frequency range: | 144-146 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5 W, Lo3: 3.5 W, Lo2: 1.5 W, Lo1: 500 mW |
| Voltage: | 13.2 VDC |
| Current drain: | RX: Max ? mA, TX: Max ? A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 49*103*35 mm |
| Weight: | 280 gr |
| Manufactured: | 1989-19xx |
| Other: | RX: 138-174 MHz. Keyboard New price 1989 in Sweden: 3495:- SEK |
| Extras: |
