| Frequency range: | TX: 144-146 MHz (Europe)
TX: 144-148 MHz (USA)
RX: 137-174 MHz |
| Mode: | FM |
| RF Power output: | Hi: 60 W
Mid: 25 W
Lo2: 10 W
Lo1: 5 W |
| Sensitivity: | Better than 0.2 uV (12 dB SINAD) |
| Selectivity: | 12 KHz (-6 dB), 28 KHz (-60 dB) |
| Image rejection: | Better than 70 dB |
| Voltage: | 13.8 VDC +/- 15% |
| Current drain: | RX: 0.3-0.7 A
TX: Max 10 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 160*50*185 mm |
| Weight: | 1.8 Kg |
| Manufactured: | 2003-200x |
| Other: | 219 memories. CTCSS and DCS. |
| Related documents: | |
