Ubuntu support
sudo apt-get update
sudo apt-get install linux-headers-$(uname -r)
sudo apt-get update
sudo apt-get install build-essential
sudo apt-get install git
sudo git clone https://github.com/lwfinger/rtl8188eu
cd rtl8188eu
sudo make all
sudo make install
sudo insmod 8188eu.ko| HARDWARE FEATURES | |
|---|---|
| Interface | USB 2.0 |
| LED | Status |
| Dimensions (W X D X H) | 0.73x0.59x0.28in.(18.6x15x7.1mm) |
| Weight | 0.07 ounces / 2.1 grams (Without packaging) |
| Antenna | Internal antenna |
| WIRELESS FEATURES | |
|---|---|
| Frequency | 2.400-2.4835GHz |
| Wireless Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Signal Rate | 11b: Up to 11Mbps (dynamic) 11g: Up to 54Mbps (dynamic) 11n: Up to 150Mbps (dynamic) |
| Reception Sensitivity | 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER |
| Transmit Power | <20dBm |
| Wireless Modes | Ad-Hoc / Infrastructure mode |
| Wireless Security | Supports 64/128 WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES), supports IEEE 802.1X |
| Modulation Technology | DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM |
| OTHERS | |
|---|---|
| Certification | CE, FCC, IC, RoHS |
| Package Contents | 150Mbps wireless N Nano USB adapter TL-WN725N Resource CD Quick Installation Guide |
| System Requirements | Windows 8(32/64bits), Windows 7(32/64bits), Windows Vista(32/64bits), Windows XP(32/64bits) |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
