| Specifications |
| Scanning system |
NTSC/PAL |
| Image sensor (device)Image size |
Sony Interline transfer Hyper HAD
CCD |
| Image size |
1/3" (approx. 4.8mm x 3.6mm) |
| Picture element all |
NTSC: 537(H) x 505(V) PAL: 537(H) x
597(V) |
| Picture element effective |
NTSC: 510(H) x 492(V) PAL: 500(H) x
582(V) |
| Obtical black elements |
Horizontal: 3:in front, 40: in back
Vertical: 12:in front, 2:in back |
| Chip size |
6.0mm (H) x 4.96mm (V) |
| Synchronizing system |
Internal sync. |
| Interlace |
2:1 interface |
| Horizontal Resolution |
Board Lens 420TV Line |
| Aperture correction |
H aperture V aperture |
| Video output level |
1.0Vp-p 75 ohms, composite |
| Video S/N ratio |
More than 50dB (AGC off) |
| Minimum illumination (AGC ON) |
Board Lens 1 Lux |
| White balance |
ATW large range:2000°K to 11000°K |
| Electronic iris |
Setting ON |
| Auto Exposure(AE) system |
Auto electronic iris: 1/50
(1/60)~1/100,000sec |
| Back light compensation |
Active Histogram plus windows weight
BLC |
| Gamma |
l |
| Built-in lens |
Board Lens 3.6mm F2.0 |
| Operating temperature |
-10°C to +50°C |
| Storage temperature |
-20°C to +70°C |
| Power requirement |
DC power supplied from coaxialcable
power supply unit |
| Power consumption |
3W |
| Dimensions (approx) |
110mm (L) x 32mm (DIA) |
| Weight (approx) |
200g |
| Power Supply |
DC power supplied from coaxialcable
power supply unit |
| Accessones & Weight |
RG-58U x 1M, Mounting Bracket,
Coaxialcable Power Supply |
