General Specifications
|
Type of Vessel
|
Anchor Handling / Rescue / Supply / Tug
|
|
|
Nationality (flag)
|
Norwegian
|
|
Port of Registry
|
Skudeneshavn
|
|
Callsign
|
LNEN
|
|
IMO Number
|
8309933
|
|
Classification DNV
|
DNV +1A1, TUG Supply Vessel, E0,
FiFi II, OIL REC., ICE C SF, DYNPOS AUT
|
|
Built
|
Bĺtservice Verft, Mandal Norway,
1984,
Hull Number 667
|
|
Gross Tonnage
|
1597
|
MT
|
|
Net Tonnage
|
618
|
MT
|
|
Dead Weight
|
2200
|
MT
|
|
Length Overall
|
67.70
|
m
|
|
Length Between Perpendiculars
|
58.80
|
m
|
|
Breadth
|
15.60
|
m
|
|
Moulded draft
|
7.45
|
m
|
|
Summer draft
|
6.40
|
m
|
|
Maximum speed
|
16.0
kts
|
|
|
Service speed
|
10.5
kts
|
|
Length Deck
Space
|
37.00 m
|
|
|
Breadth Deck
Space
|
12.80 m
|
|
Maximum Deck
Load
|
908.00 T
|
|
Deck Strength
per m2
|
5.00 T/m2
|
|
MMSI Number
|
257244000
|
|
|
Sat-C
|
425724410
|
|
4 x MAN B&W
Main Engine
Type Alpha 12u
|
4 x 2340 kW / 3182 BHP @ 775 RPM
|
|
|
2 x Shaft Generator,
Type A. van Kaick DIDB 130HI/4-d
|
2 x 2725 kVA / 2180 kW @ 1800 RPM
|
|
2 x GM Detroit
Diesel Allison Aux. Engine
Type 8V-92T, modelnumber 80837305
|
2 x 280 kW @ 1800 RPM
|
|
|
2 x Stamford
Auxiliary Generator
Type M5C / 53C
|
2 x 350 kVA / 280 kW @ 1800 RPM
|
|
1 x Stamford
Port / Emergency Generator
Type MSC 434 B
|
1 x 200 kVA / 160 kW @ 1800 RPM
|
|
|
1 x Transverse Bow Tunnel Thruster,
make Brunvoll, type
SPR-VP 3577
|
Input speed 890 RPM
|
|
|
1 x Transverse Bow Tunnel Thruster,
make Brunvoll, type
SPR-VP 3578
|
Input speed 890 RPM
|
|
1 x Transverse Stern Tunnel Thruster,
make Brunvoll, type
SPR-VP 3579
|
Input speed 1188 RPM
|
|
Main Gear
|
2 x Lohmann & Stolterfoht
|
|
Main Propellers, Type Alpha Diesel
|
Speed Engine / Propeller 750 / 190
RPM
|
|
Simrad Albatros Dynamic Positioning
|
|
|
|
