General Specifications
|
Type of Vessel
|
Shuttle Tanker
|
|
|
Nationality (flag)
|
Bahamas
|
|
Callsign
|
C6FS8
|
|
IMO Number
|
9000948
|
|
Classification DP Class 1
(Det Norske Veritas)
|
+1A1, TFO, PP3, E0, DYNPOS AUT,
BOW LOADING, HELDK, with register notations: inert, cow & FMEA
|
|
Delivered by :
Tsuneishi Shipbuilding Co., Ltd.
|
Japan, November, 1991, Hull
number 654
|
|
Converted to DP Shuttle Tanker by :
Tsuneishi Shipbuilding Co., Ltd.
|
Japan, November, 1996
|
|
Gross Tonnage
|
58928
|
MT
|
|
Net Tonnage
|
31088
|
MT
|
|
Suez Gross Tonnage
|
59204.6
|
MT
|
|
Suez Net Tonnage
|
51574.4
|
MT
|
|
Light Ship Displacement
|
17081
|
MT
|
|
Deadweight @ Summer Draft
|
107,223
|
MT
|
|
Length Overall
|
246.70
|
m
|
|
Length Between Perpendiculars
|
233.30
|
m
|
|
Breadth Moulded
|
42.00
|
m
|
|
Moulded Depth
|
21.50
|
m
|
|
Design draft
|
12.19
|
m
|
|
Draft extreme on summer freeboard
|
15.02
|
m
|
|
Air draft
|
47.98
|
m
|
|
Average servicespeed
|
14.5 kts
|
|
|
Cruiseingrange
|
23,000 NM
|
|
1 x Hosehandling Crane
|
SWL 15 T x 23 m Working Radius
|
|
|
1 x Provision Crane
|
SWL 4 T x 11.5 m Working Radius
|
|
Helicopter Deck
|
D Value = 23 M, max. Weight 9,3
MT
|
|
|
1 x Mitsui B&W Main Engine
Type 7S60 MC
|
11,300 kW @ 88 RPM
|
|
|
3 x Ssangyong
B&W Aux Engine
Type 5L23/30
|
600 kW @ 720 RPM each
|
|
2 x Man B&W
Aux Engine
Type 8L 28/32H
|
1,675 kW @ 720 RPM each
|
|
1 x Yanmar Emcy
Gen-type 6 HAL-H
|
100 kW @ 1800 RPM
|
|
2 x Ulstein Bow Tunnel Thruster
|
1500 HP each
|
|
|
1 x Ulstein Stern Tunnel Thruster
|
1500 HP
|
|
1 x 4 bladed Ulstein Main Propeller,
type CPP with 0-pitch
system
|
Diameter of Main Propeller : 7000
mm
|
|
Kongsberg Simrad Dynamic Positioning
|
ADP721 + Artemis MK4, 2 x DARPS &
HiPap500
|
|
|
