DIAL Repeater Systems

W8BLV/W8JEU Dial Radio Club Repeater Systems Acceptable Use Policy and Basic Rules

This document originated with the WB4GBI repeater system. The document was revised and used with their permission.

Please Read This Policy Before Use

Rosedale Rd, Middletown, Ohio Site

W8BLV Analog Repeater:

W8BLV 146.610 MHz (-600 KHz input) Analog Repeater, PL 77.0 Hz, 80 watts output
Repeater is linked to the Walton Ct site 444.825 MHz (+5 MHz input) repeater
It has been on the air since the early 1970’s
There are two remote receivers that are located at the Walton Ct site and the Britton Ln site

Other Rosedale Rd Site Information:

System has Echolink on node # 323719 and other special functions using a CAT-1000 controller
Antenna is 340 feet above ground located on the side of the commercial radio broadcast tower
Battery backup for power losses
See Rosedale Rd Photos below

Walton Ct, Middletown, Ohio Site

W8BLV Analog Repeater:

W8BLV 444.825 MHz (+5 MHz input) Analog Repeater, PL 77.0 Hz
Repeater is linked to the Rosedale Rd site 146.610 (-600 KHz input) repeater

W8BLV Digital Repeater:

W8BLV 444.3625  MHz (+5 MHz input) Digital Mobile Radio (DMR) Repeater, Color Code of 1
Repeater was installed in November 2014.  It is connected to the World Wide Brandmeister DMR network via the Internet
It provides high quality digital voice communications to several thousands of other DMR repeaters

Time Slot 2:
*Ohio State talkgroup 3139 - On all the time
*Local 2 cluster - On all the time
*Local 9 - On all the time

Time Slot 1:
All other talkgroups must use time slot 1, and are push to talk (PTT) activated.

Detailed talkgroup information is here: Brandmeister Talkgroups

W8BLV APRS Packet Radio System:

W8BLV 144.39 MHz Digipeater output is 25 watts.

Other Walton Ct Site Information:

W8BLV 146.010 Remote Analog Receiver for the Rosedale Rd site repeater
Antenna is located on the commercial cell tower, 150 feet above ground

Britton Ln, Monroe, Ohio Site

W8JEU Analog and Digital Repeater:

W8JEU 147.315 MHz (+600 KHz input) Repeater, PL 77.0 Hz
Yaesu Fusion DR-1X repeater has automatic and user selectable FM and C4FM digital modes
Repeater only has CW ID (no courtesy tone) with 20 watts output

Other Britton Lane Site Information:

Dual band (2m/10cm) Comet GP-9 antenna is 100 feet above ground on top of the water tower
The W8MUM Repeater shares the antenna on 443.5375, PL 94.8 and is open to all users.
146.010 Remote Analog Receiver for the Rosedale Rd site repeater
Small battery is used until the generator turns on for power losses
See Britton Ln Photos below
