Large Modular Amplifiers

  1. Mini-Circuits ZHL-1A (BNC) with wired modular power jack, 2-500 MHz, 20 dB gain, +28 dBm
  2. Mini-Circuits ZHL-2 (BNC) with wired modular power jack, 10-1000 MHz, 16 dB gain, +29 dBm
  3. Mini-Circuits ZHL-1042J (SMA), Qty 2
  4. Mini-Circuits ZHL-42 (SMA), 600-4200 MHz, +38 dB gain, +28 dBm
  5. Mini-Circuits ZHL-2-BNC, 10-1000 MHz, 16 dB gain, +29 dBm
  6. Mini-Circuits ZHL-1217MLN-SMA, 1.2-1.7 GHz, 29 dB gain, Low Noise +22 dBm
  7. Mini-Circuits ZHL-1042J in Amplifier Research LN1000 enclosure
  8. Mini-Circuits ZFL-2000 in HP 8447E enclosure
  9. HP 11729-60086 IF Amplifier 5-1280 MHz, +15V
  10. HP 11729-60071 Power Amplifier 640 MHz, +15V (with comb generator attached)
  11. HP 11729-60014 Low Noise Amplifier 10Hz - 25 MHz, +24V

Modular AC/DC Power Supply

  1. +12 V DC @ 8 A with wired modular DC power jack
  2. +24 V DC @ 0.75 A with wired modular DC power jack
  3. +24 V DC @ 1.2 A with wired modular DC power jack

Small Modular RF Amplifiers

Partial listing below...

  1. Mini-Circuits ZFL-500LN, Qty 2
  2. Mini-Circuits ZFL-2000, Qty 3
  3. Mini-Circuits AH-42
  4. Mini-Circuits ZX60-33LN, Qty 2
  5. Amplica, Inc 200 USL, Qty 2
  6. WJ CA12, 10-1000 MHz, 16 dB, +15VDC
  7. WJ CA36, 100-2300 MHz, 16.2 dB, +12 dBm, +15VDC
  8. Cougar Components AC2546, Qty 2
  9. Cougar Components A2C4152
  10. Cougar Components AP1053C
  11. Miteq Amplifiers, 2-18 GHz, Qty 2
  12. DIY, 50-600 MHz, >20 dB gain
  13. DIY, 2-400 MHz, 22 dB gain

All amplifiers with protective connector caps (or in original packaging) are tested and known to be good.
